High-precision laser cutting machine
Classification:
Equipment features:
- Product parameters
- Application fields
-
Radio frequency CO₂ laser cutting machine is a CO₂ laser cutting device using radio frequency excitation technology. It generates a high-energy laser beam by exciting gas (CO₂ mixed gas) with a radio frequency electromagnetic field for precision cutting of metal or non-metal materials.
Work Area
500*500mm
Laser Power
30-150W Optional
Laser Type
Imported CO2 sealed RF laser
Lens
Imported reflector lens
Cooling Type
Air cooling/Water cooling system
Cutting Speed
200mm/s
Laser Energy Control
0-100% software setting
Minimum Forming Text
Chinese characters: 2.0mm*2:0mm, English: 1.0mm*1.0mm
Positioning Accuracy
≤±0.01mm
Control Software
DSP control system
Supported Graphic Formats
PLT、DXF、Al、LAS etc.
Motion System
Linear module
Auxiliary Device
Vacuum adsorption, internal exhaust fan
Working Environment
Humidity 40%
Power Supply
AC110V/220V±10%,50HZ/60HZ
Base Plate Configuration
Knife bar table, honeycomb table,Steel table,Rotary device, automatic laser focusing systemSystem
Key words:
High-precision laser cutting machine
